Pathway Description
Starch and Sucrose Metabolism
Mus musculus
Category:
Metabolite Pathway
Sub-Category:
Metabolic
Created: 2018-01-21
Last Updated: 2019-09-15
Amylase enzymes secreted in saliva by the parotid gland and in the small intestine play an important role in initiating starch digestion. The products of starch digestion are but not limited to maltotriose, maltose, limit dextrin, and glucose. The action of enterocytes of the small intestine microvilli further break down limit dextrins and disaccharides into monosaccharides: glucose, galactose, and fructose. Once released from starch or once ingested, sucrose can be degraded into beta-D-fructose and alpha-D-glucose via lysosomal alpha-glucosidase or sucrose-isomaltase. Beta-D-fructose can be converted to beta-D-fructose-6-phosphate by glucokinase and then to alpha-D-glucose-6-phosphate by the action of glucose phosphate isomerase. Phosphoglucomutase 1 can then act on alpha-D-glucose-6-phosphate (G6P) to generate alpha-D-glucose-1-phosphate. Alpha-D-glucose-1-phosphate (G6P) has several possible fates. It can enter into gluconeogenesis, glycolysis or the nucleotide sugar metabolism pathway. UDP-glucose pyrophosphorylase 2 can convert alpha-D-glucose-1-phosphate into UDP-glucose, which can then be converted to UDP-xylose or UDP-glucuronate and, eventually to glucuronate. UDP-glucose can also serve as a precursor to the synthesis of glycogen via glycogen synthase. Glycogen is an analogue of amylopectin (“plant starch”) and acts as a secondary short-term energy storage for animal cells. It’s formed primarily in liver and muscle tissues, but is also formed at secondary sites such as the central nervous system and the stomach. In both cases it exists as free granules in the cytosol. Glycogen is a crucial element of the glucose cycle as another enzyme, glycogen phosphorylase, cleaves off glycogen from the nonreducing ends of a chain to producer glucose-1-phosphate monomers. From there, the glucose-1-phosphate monomers have three possible fates: (1) enter the glycolysis pathway as glucose-6—phosphate (G6P) to generate energy, (2) enter the pentose phosphate pathway to produce NADPH and pentose sugar, or (3) enter the gluconeogenesis pathway by being dephosphorylated into glucose in liver or kidney tissues.
To initiate the process of glycogen chain-lengthening, glycogenin is required because glycogen synthase can only add to existing chains. This action is subsequently followed by the action of glycogen synthase which catalyzes the formation of polymers of UDP-glucose connected by (α1→4) glycosidic bonds to form a glycogen chain. Importantly, amylo (α1→4) to (α1→6) transglycosylase catalyzes glycogen branch formation via the transfer of 6-7 glucose residues from a nonreducing end with greater than 11 residues to the C-6 OH- group in the interior of a glycogen molecule.
References
Starch and Sucrose Metabolism References
Lehninger, A.L. Lehninger principles of biochemistry (4th ed.) (2005). New York: W.H Freeman.
Salway, J.G. Metabolism at a glance (3rd ed.) (2004). Alden, Mass.: Blackwell Pub.
Heikkinen S, Suppola S, Malkki M, Deeb SS, Janne J, Laakso M: Mouse hexokinase II gene: structure, cDNA, promoter analysis, and expression pattern. Mamm Genome. 2000 Feb;11(2):91-6.
Pubmed: 10656921
Gerhard DS, Wagner L, Feingold EA, Shenmen CM, Grouse LH, Schuler G, Klein SL, Old S, Rasooly R, Good P, Guyer M, Peck AM, Derge JG, Lipman D, Collins FS, Jang W, Sherry S, Feolo M, Misquitta L, Lee E, Rotmistrovsky K, Greenhut SF, Schaefer CF, Buetow K, Bonner TI, Haussler D, Kent J, Kiekhaus M, Furey T, Brent M, Prange C, Schreiber K, Shapiro N, Bhat NK, Hopkins RF, Hsie F, Driscoll T, Soares MB, Casavant TL, Scheetz TE, Brown-stein MJ, Usdin TB, Toshiyuki S, Carninci P, Piao Y, Dudekula DB, Ko MS, Kawakami K, Suzuki Y, Sugano S, Gruber CE, Smith MR, Simmons B, Moore T, Waterman R, Johnson SL, Ruan Y, Wei CL, Mathavan S, Gunaratne PH, Wu J, Garcia AM, Hulyk SW, Fuh E, Yuan Y, Sneed A, Kowis C, Hodgson A, Muzny DM, McPherson J, Gibbs RA, Fahey J, Helton E, Ketteman M, Madan A, Rodrigues S, Sanchez A, Whiting M, Madari A, Young AC, Wetherby KD, Granite SJ, Kwong PN, Brinkley CP, Pearson RL, Bouffard GG, Blakesly RW, Green ED, Dickson MC, Rodriguez AC, Grimwood J, Schmutz J, Myers RM, Butterfield YS, Griffith M, Griffith OL, Krzywinski MI, Liao N, Morin R, Palmquist D, Petrescu AS, Skalska U, Smailus DE, Stott JM, Schnerch A, Schein JE, Jones SJ, Holt RA, Baross A, Marra MA, Clifton S, Makowski KA, Bosak S, Malek J: The status, quality, and expansion of the NIH full-length cDNA project: the Mammalian Gene Collection (MGC). Genome Res. 2004 Oct;14(10B):2121-7. doi: 10.1101/gr.2596504.
Pubmed: 15489334
Chiara F, Castellaro D, Marin O, Petronilli V, Brusilow WS, Juhaszova M, Sollott SJ, Forte M, Bernardi P, Rasola A: Hexokinase II detachment from mitochondria triggers apoptosis through the permeability transition pore independent of voltage-dependent anion channels. PLoS One. 2008 Mar 19;3(3):e1852. doi: 10.1371/journal.pone.0001852.
Pubmed: 18350175
Gurney ME, Heinrich SP, Lee MR, Yin HS: Molecular cloning and expression of neuroleukin, a neurotrophic factor for spinal and sensory neurons. Science. 1986 Oct 31;234(4776):566-74. doi: 10.1126/science.3764429.
Pubmed: 3764429
Carninci P, Kasukawa T, Katayama S, Gough J, Frith MC, Maeda N, Oyama R, Ravasi T, Lenhard B, Wells C, Kodzius R, Shimokawa K, Bajic VB, Brenner SE, Batalov S, Forrest AR, Zavolan M, Davis MJ, Wilming LG, Aidinis V, Allen JE, Ambesi-Impiombato A, Apweiler R, Aturaliya RN, Bailey TL, Bansal M, Baxter L, Beisel KW, Bersano T, Bono H, Chalk AM, Chiu KP, Choudhary V, Christoffels A, Clutterbuck DR, Crowe ML, Dalla E, Dalrymple BP, de Bono B, Della Gatta G, di Bernardo D, Down T, Engstrom P, Fagiolini M, Faulkner G, Fletcher CF, Fukushima T, Furuno M, Futaki S, Gariboldi M, Georgii-Hemming P, Gingeras TR, Gojobori T, Green RE, Gustincich S, Harbers M, Hayashi Y, Hensch TK, Hirokawa N, Hill D, Huminiecki L, Iacono M, Ikeo K, Iwama A, Ishikawa T, Jakt M, Kanapin A, Katoh M, Kawasawa Y, Kelso J, Kitamura H, Kitano H, Kollias G, Krishnan SP, Kruger A, Kummerfeld SK, Kurochkin IV, Lareau LF, Lazarevic D, Lipovich L, Liu J, Liuni S, McWilliam S, Madan Babu M, Madera M, Marchionni L, Matsuda H, Matsuzawa S, Miki H, Mignone F, Miyake S, Morris K, Mottagui-Tabar S, Mulder N, Nakano N, Nakauchi H, Ng P, Nilsson R, Nishiguchi S, Nishikawa S, Nori F, Ohara O, Okazaki Y, Orlando V, Pang KC, Pavan WJ, Pavesi G, Pesole G, Petrovsky N, Piazza S, Reed J, Reid JF, Ring BZ, Ringwald M, Rost B, Ruan Y, Salzberg SL, Sandelin A, Schneider C, Schonbach C, Sekiguchi K, Semple CA, Seno S, Sessa L, Sheng Y, Shibata Y, Shimada H, Shimada K, Silva D, Sinclair B, Sperling S, Stupka E, Sugiura K, Sultana R, Takenaka Y, Taki K, Tammoja K, Tan SL, Tang S, Taylor MS, Tegner J, Teichmann SA, Ueda HR, van Nimwegen E, Verardo R, Wei CL, Yagi K, Yamanishi H, Zabarovsky E, Zhu S, Zimmer A, Hide W, Bult C, Grimmond SM, Teasdale RD, Liu ET, Brusic V, Quackenbush J, Wahlestedt C, Mattick JS, Hume DA, Kai C, Sasaki D, Tomaru Y, Fukuda S, Kanamori-Katayama M, Suzuki M, Aoki J, Arakawa T, Iida J, Imamura K, Itoh M, Kato T, Kawaji H, Kawagashira N, Kawashima T, Kojima M, Kondo S, Konno H, Nakano K, Ninomiya N, Nishio T, Okada M, Plessy C, Shibata K, Shiraki T, Suzuki S, Tagami M, Waki K, Watahiki A, Okamura-Oho Y, Suzuki H, Kawai J, Hayashizaki Y: The transcriptional landscape of the mammalian genome. Science. 2005 Sep 2;309(5740):1559-63. doi: 10.1126/science.1112014.
Pubmed: 16141072
Church DM, Goodstadt L, Hillier LW, Zody MC, Goldstein S, She X, Bult CJ, Agarwala R, Cherry JL, DiCuccio M, Hlavina W, Kapustin Y, Meric P, Maglott D, Birtle Z, Marques AC, Graves T, Zhou S, Teague B, Potamousis K, Churas C, Place M, Herschleb J, Runnheim R, Forrest D, Amos-Landgraf J, Schwartz DC, Cheng Z, Lindblad-Toh K, Eichler EE, Ponting CP: Lineage-specific biology revealed by a finished genome assembly of the mouse. PLoS Biol. 2009 May 5;7(5):e1000112. doi: 10.1371/journal.pbio.1000112. Epub 2009 May 26.
Pubmed: 19468303
Ishimura-Oka K, Nakamuta M, Chu MJ, Sullivan M, Chan L, Oka K: Partial structure of the mouse glucokinase gene. Genomics. 1995 Oct 10;29(3):751-4.
Pubmed: 8575769
Postic C, Niswender KD, Decaux JF, Parsa R, Shelton KD, Gouhot B, Pettepher CC, Granner DK, Girard J, Magnuson MA: Cloning and characterization of the mouse glucokinase gene locus and identification of distal liver-specific DNase I hypersensitive sites. Genomics. 1995 Oct 10;29(3):740-50. doi: 10.1006/geno.1995.9943.
Pubmed: 8575768
Bonthron DT, Sultan P, Collins T: Structure of the murine c-sis proto-oncogene (Sis, PDGFB) encoding the B chain of platelet-derived growth factor. Genomics. 1991 May;10(1):287-92.
Pubmed: 2045107
Leveen P, Pekny M, Gebre-Medhin S, Swolin B, Larsson E, Betsholtz C: Mice deficient for PDGF B show renal, cardiovascular, and hematological abnormalities. Genes Dev. 1994 Aug 15;8(16):1875-87. doi: 10.1101/gad.8.16.1875.
Pubmed: 7958863
Maliekal P, Sokolova T, Vertommen D, Veiga-da-Cunha M, Van Schaftingen E: Molecular identification of mammalian phosphopentomutase and glucose-1,6-bisphosphate synthase, two members of the alpha-D-phosphohexomutase family. J Biol Chem. 2007 Nov 2;282(44):31844-51. doi: 10.1074/jbc.M706818200. Epub 2007 Sep 5.
Pubmed: 17804405
Fuchs S, Resch K, Thiel C, Ulbrich M, Platzer M, Jockusch H, Schmitt-John T: Comparative transcription map of the wobbler critical region on mouse chromosome 11 and the homologous region on human chromosome 2p13-14. BMC Genet. 2002 Aug 13;3:14. Epub 2002 Aug 13.
Pubmed: 12174196
Doi R, Oishi K, Ishida N: CLOCK regulates circadian rhythms of hepatic glycogen synthesis through transcriptional activation of Gys2. J Biol Chem. 2010 Jul 16;285(29):22114-21. doi: 10.1074/jbc.M110.110361. Epub 2010 Apr 29.
Pubmed: 20430893
This pathway was propagated using PathWhiz -
Pon, A. et al. Pathways with PathWhiz (2015) Nucleic Acids Res. 43(Web Server issue): W552–W559.
Propagated from SMP0000058
