Pathway Description
Pyrimidine Metabolism
Rattus norvegicus
Category:
Metabolite Pathway
Sub-Category:
Metabolic
Created: 2018-08-10
Last Updated: 2019-09-15
A group of heterocyclic aromatic organic compound, pyrimidines are similar in structure to benzene and pyridine and count the nucleic acids cytosine, thymine, and uracil as structural derivatives. The following pathway illustrates a many pyrimidine-associated processes such as nucleotide biosynthesis, degradation, and salvage. This pathway depicts a number of pyrimidine-related processes such as nucleotide biosynthesis, degradation, and salvage. For pyrimidine nucleotide biosynthesis, carbamoyl phosphate derived from the action of carbamoyl phosphate synthetase II (CPS-II) on glutamine and bicarbonate is converted into carbamoyl aspartate by aspartate transcarbamoylase, ATCase. Dihydroorotic acid is subsequently generated by the action of carbamoyl aspartate dehydrogenase on carbamoyl aspartate. Dihydroorotate dehydrogenase then converts dihydroorotic acid to orotic acid. From this point, orotate phosphoribosyltransferase incorporates phosphoribosyl pyrophosphate into (PRPP) to produce orotidine monophosphate. Orotidine-5’-phosphate carboxylase subsequently converts orotidine monophosphate into uridine monophosphate (UMP). UMP is further phosphorylated twice to form UTP; the first instance by uridylate kinase and the second instance by ubiquitous nucleoside diphosphate kinase. UTP moves into the CTP synthesis pathway with the action of CTP synthase which aminates the molecule.
The uridine nucleotides are also feedstock for the de novo thymine nucleotides synthesis pathway. DeoxyUMP which is derived from UDP or CDP metabolism is transformed by the action of thymidylate synthase into deoxyTMP of which the methyl group is sourced from N5,N10-methylene THF. THF is subsequently regenerated from DHF via dihydrofolate reductase (DHFR) which is essential for the continuation of thymidylate synthase activity. Serine hydroxymethyl transferase then acts on THF to regenerate N5,N10-THF.
Pyrimidine synthesis is a comparatively simpler process than purine synthesis due to a couple of factors; pyrimidine ring structure is assembled as a free base rather being derived from PRPP and there is no branch in the pyrimidine synthesis pathway as opposed to the purine synthesis pathway. For thymidine, the action of thymidine kinase on it (or alternatively deoxyuridine) plays an important role in what is referred to as the salvage pathway to dTTP synthesis. However to form dTMP, the action of thymine phosphorylase and thymidine kinase is required. For deoxycytidine, deoxycytidine kinase is required (deoxycytidine also acts on deoxyadenosine and deoxyguanosine). For uracil, UMP can be formed by the action of uridine phosphorylase and uridine kinase on uracil. Pyrimidine catabolism ultimately results in the formation of the waste products of urea, H2O, and CO2. The product of cytosine breakdown, uracil, can be broken down to N-carbamoyl-β-alanine which can be catabolized into β-alanine. The product of thymine breakdown is β-aminoisobutyrate. The transamination of α-ketoglutarate to glutamate requires both of these breakdown products (β-alanine and β-aminoisobutyrate) to act as amine group donors. The products of this transamination can move through a further reaction that produces malonyl-CoA or methylmalonyl-CoA, a precursor for succinyl-CoA which is used in the Krebs cycle.
References
Pyrimidine Metabolism References
Nyunoya H, Broglie KE, Widgren EE, Lusty CJ: Characterization and derivation of the gene coding for mitochondrial carbamyl phosphate synthetase I of rat. J Biol Chem. 1985 Aug 5;260(16):9346-56.
Pubmed: 2991241
Lagace M, Howell BW, Burak R, Lusty CJ, Shore GC: Rat carbamyl-phosphate synthetase I gene. Promoter sequence and tissue-specific transcriptional regulation in vitro. J Biol Chem. 1987 Aug 5;262(22):10415-8.
Pubmed: 3038878
Pekkala S, Martinez AI, Barcelona B, Gallego J, Bendala E, Yefimenko I, Rubio V, Cervera J: Structural insight on the control of urea synthesis: identification of the binding site for N-acetyl-L-glutamate, the essential allosteric activator of mitochondrial carbamoyl phosphate synthetase. Biochem J. 2009 Nov 11;424(2):211-20. doi: 10.1042/BJ20090888.
Pubmed: 19754428
Rotgeri A, Loffler M: Molecular cloning and sequence analyses of rat liver dihydroorotate dehydrogenase. Adv Exp Med Biol. 1994;370:693-7. doi: 10.1007/978-1-4615-2584-4_144.
Pubmed: 7660999
Rawls J, Knecht W, Diekert K, Lill R, Loffler M: Requirements for the mitochondrial import and localization of dihydroorotate dehydrogenase. Eur J Biochem. 2000 Apr;267(7):2079-87. doi: 10.1046/j.1432-1327.2000.01213.x.
Pubmed: 10727948
Hansen M, Le Nours J, Johansson E, Antal T, Ullrich A, Loffler M, Larsen S: Inhibitor binding in a class 2 dihydroorotate dehydrogenase causes variations in the membrane-associated N-terminal domain. Protein Sci. 2004 Apr;13(4):1031-42. doi: 10.1110/ps.03533004.
Pubmed: 15044733
Failer BU, Braun N, Zimmermann H: Cloning, expression, and functional characterization of a Ca(2+)-dependent endoplasmic reticulum nucleoside diphosphatase. J Biol Chem. 2002 Oct 4;277(40):36978-86. doi: 10.1074/jbc.M201656200. Epub 2002 Aug 6.
Pubmed: 12167635
Gerhard DS, Wagner L, Feingold EA, Shenmen CM, Grouse LH, Schuler G, Klein SL, Old S, Rasooly R, Good P, Guyer M, Peck AM, Derge JG, Lipman D, Collins FS, Jang W, Sherry S, Feolo M, Misquitta L, Lee E, Rotmistrovsky K, Greenhut SF, Schaefer CF, Buetow K, Bonner TI, Haussler D, Kent J, Kiekhaus M, Furey T, Brent M, Prange C, Schreiber K, Shapiro N, Bhat NK, Hopkins RF, Hsie F, Driscoll T, Soares MB, Casavant TL, Scheetz TE, Brown-stein MJ, Usdin TB, Toshiyuki S, Carninci P, Piao Y, Dudekula DB, Ko MS, Kawakami K, Suzuki Y, Sugano S, Gruber CE, Smith MR, Simmons B, Moore T, Waterman R, Johnson SL, Ruan Y, Wei CL, Mathavan S, Gunaratne PH, Wu J, Garcia AM, Hulyk SW, Fuh E, Yuan Y, Sneed A, Kowis C, Hodgson A, Muzny DM, McPherson J, Gibbs RA, Fahey J, Helton E, Ketteman M, Madan A, Rodrigues S, Sanchez A, Whiting M, Madari A, Young AC, Wetherby KD, Granite SJ, Kwong PN, Brinkley CP, Pearson RL, Bouffard GG, Blakesly RW, Green ED, Dickson MC, Rodriguez AC, Grimwood J, Schmutz J, Myers RM, Butterfield YS, Griffith M, Griffith OL, Krzywinski MI, Liao N, Morin R, Palmquist D, Petrescu AS, Skalska U, Smailus DE, Stott JM, Schnerch A, Schein JE, Jones SJ, Holt RA, Baross A, Marra MA, Clifton S, Makowski KA, Bosak S, Malek J: The status, quality, and expansion of the NIH full-length cDNA project: the Mammalian Gene Collection (MGC). Genome Res. 2004 Oct;14(10B):2121-7. doi: 10.1101/gr.2596504.
Pubmed: 15489334
Gibbs RA, Weinstock GM, Metzker ML, Muzny DM, Sodergren EJ, Scherer S, Scott G, Steffen D, Worley KC, Burch PE, Okwuonu G, Hines S, Lewis L, DeRamo C, Delgado O, Dugan-Rocha S, Miner G, Morgan M, Hawes A, Gill R, Celera, Holt RA, Adams MD, Amanatides PG, Baden-Tillson H, Barnstead M, Chin S, Evans CA, Ferriera S, Fosler C, Glodek A, Gu Z, Jennings D, Kraft CL, Nguyen T, Pfannkoch CM, Sitter C, Sutton GG, Venter JC, Woodage T, Smith D, Lee HM, Gustafson E, Cahill P, Kana A, Doucette-Stamm L, Weinstock K, Fechtel K, Weiss RB, Dunn DM, Green ED, Blakesley RW, Bouffard GG, De Jong PJ, Osoegawa K, Zhu B, Marra M, Schein J, Bosdet I, Fjell C, Jones S, Krzywinski M, Mathewson C, Siddiqui A, Wye N, McPherson J, Zhao S, Fraser CM, Shetty J, Shatsman S, Geer K, Chen Y, Abramzon S, Nierman WC, Havlak PH, Chen R, Durbin KJ, Egan A, Ren Y, Song XZ, Li B, Liu Y, Qin X, Cawley S, Worley KC, Cooney AJ, D'Souza LM, Martin K, Wu JQ, Gonzalez-Garay ML, Jackson AR, Kalafus KJ, McLeod MP, Milosavljevic A, Virk D, Volkov A, Wheeler DA, Zhang Z, Bailey JA, Eichler EE, Tuzun E, Birney E, Mongin E, Ureta-Vidal A, Woodwark C, Zdobnov E, Bork P, Suyama M, Torrents D, Alexandersson M, Trask BJ, Young JM, Huang H, Wang H, Xing H, Daniels S, Gietzen D, Schmidt J, Stevens K, Vitt U, Wingrove J, Camara F, Mar Alba M, Abril JF, Guigo R, Smit A, Dubchak I, Rubin EM, Couronne O, Poliakov A, Hubner N, Ganten D, Goesele C, Hummel O, Kreitler T, Lee YA, Monti J, Schulz H, Zimdahl H, Himmelbauer H, Lehrach H, Jacob HJ, Bromberg S, Gullings-Handley J, Jensen-Seaman MI, Kwitek AE, Lazar J, Pasko D, Tonellato PJ, Twigger S, Ponting CP, Duarte JM, Rice S, Goodstadt L, Beatson SA, Emes RD, Winter EE, Webber C, Brandt P, Nyakatura G, Adetobi M, Chiaromonte F, Elnitski L, Eswara P, Hardison RC, Hou M, Kolbe D, Makova K, Miller W, Nekrutenko A, Riemer C, Schwartz S, Taylor J, Yang S, Zhang Y, Lindpaintner K, Andrews TD, Caccamo M, Clamp M, Clarke L, Curwen V, Durbin R, Eyras E, Searle SM, Cooper GM, Batzoglou S, Brudno M, Sidow A, Stone EA, Venter JC, Payseur BA, Bourque G, Lopez-Otin C, Puente XS, Chakrabarti K, Chatterji S, Dewey C, Pachter L, Bray N, Yap VB, Caspi A, Tesler G, Pevzner PA, Haussler D, Roskin KM, Baertsch R, Clawson H, Furey TS, Hinrichs AS, Karolchik D, Kent WJ, Rosenbloom KR, Trumbower H, Weirauch M, Cooper DN, Stenson PD, Ma B, Brent M, Arumugam M, Shteynberg D, Copley RR, Taylor MS, Riethman H, Mudunuri U, Peterson J, Guyer M, Felsenfeld A, Old S, Mockrin S, Collins F: Genome sequence of the Brown Norway rat yields insights into mammalian evolution. Nature. 2004 Apr 1;428(6982):493-521. doi: 10.1038/nature02426.
Pubmed: 15057822
Mehus JG, Deloukas P, Lambeth DO: NME6: a new member of the nm23/nucleoside diphosphate kinase gene family located on human chromosome 3p21.3. Hum Genet. 1999 Jun;104(6):454-9. doi: 10.1007/s004390050987.
Pubmed: 10453732
Tanabe T, Yamada M, Noma T, Kajii T, Nakazawa A: Tissue-specific and developmentally regulated expression of the genes encoding adenylate kinase isozymes. J Biochem. 1993 Feb;113(2):200-7. doi: 10.1093/oxfordjournals.jbchem.a124026.
Pubmed: 8468325
This pathway was propagated using PathWhiz -
Pon, A. et al. Pathways with PathWhiz (2015) Nucleic Acids Res. 43(Web Server issue): W552–W559.
