Pathway Description
CXCR4 Signaling Pathway
Rattus norvegicus
Category:
Protein Pathway
Sub-Categories:
Cytokine Signaling
Immunological
Pathogen-Activated Signaling
Kinase Signaling
Gene Regulatory
Cellular Response
Created: 2018-09-20
Last Updated: 2019-08-16
CXCR4 is a chemokine G-protein-coupled receptor. Chemokine receptors couple to the pertussis toxin-sensitive Gi proteins. It is involved in organogenesis, hematopoiesis, and the immune response. Chemokine stromal cell-derived factor 1 (SDF-1) binds CXCR4. CXCR4 is also a co-receptor for HIV and is involved in the metastasis of some cancers. Pertussis toxin ADP-ribosylates guanine nucleotide binding protein alpha inhibiting (Gai) proteins inhibiting GPCR/Gi coupling. Activated Gai inhibits adenylyl cyclase and activates tyrosine kinases, while activated guanine nucleotide binding protein beta and gamma activate PI3K - regulating gene transcription, cell migration, and cell adhesion. PLC is activated to cause the cleavage of PIP2 to IP3 and DG. This leads to the increase of calcium from the endoplasmic reticulum and the activation of protein kinase C.
References
CXCR4 Signaling Pathway References
Gerhard DS, Wagner L, Feingold EA, Shenmen CM, Grouse LH, Schuler G, Klein SL, Old S, Rasooly R, Good P, Guyer M, Peck AM, Derge JG, Lipman D, Collins FS, Jang W, Sherry S, Feolo M, Misquitta L, Lee E, Rotmistrovsky K, Greenhut SF, Schaefer CF, Buetow K, Bonner TI, Haussler D, Kent J, Kiekhaus M, Furey T, Brent M, Prange C, Schreiber K, Shapiro N, Bhat NK, Hopkins RF, Hsie F, Driscoll T, Soares MB, Casavant TL, Scheetz TE, Brown-stein MJ, Usdin TB, Toshiyuki S, Carninci P, Piao Y, Dudekula DB, Ko MS, Kawakami K, Suzuki Y, Sugano S, Gruber CE, Smith MR, Simmons B, Moore T, Waterman R, Johnson SL, Ruan Y, Wei CL, Mathavan S, Gunaratne PH, Wu J, Garcia AM, Hulyk SW, Fuh E, Yuan Y, Sneed A, Kowis C, Hodgson A, Muzny DM, McPherson J, Gibbs RA, Fahey J, Helton E, Ketteman M, Madan A, Rodrigues S, Sanchez A, Whiting M, Madari A, Young AC, Wetherby KD, Granite SJ, Kwong PN, Brinkley CP, Pearson RL, Bouffard GG, Blakesly RW, Green ED, Dickson MC, Rodriguez AC, Grimwood J, Schmutz J, Myers RM, Butterfield YS, Griffith M, Griffith OL, Krzywinski MI, Liao N, Morin R, Palmquist D, Petrescu AS, Skalska U, Smailus DE, Stott JM, Schnerch A, Schein JE, Jones SJ, Holt RA, Baross A, Marra MA, Clifton S, Makowski KA, Bosak S, Malek J: The status, quality, and expansion of the NIH full-length cDNA project: the Mammalian Gene Collection (MGC). Genome Res. 2004 Oct;14(10B):2121-7. doi: 10.1101/gr.2596504.
Pubmed: 15489334
Gibbs RA, Weinstock GM, Metzker ML, Muzny DM, Sodergren EJ, Scherer S, Scott G, Steffen D, Worley KC, Burch PE, Okwuonu G, Hines S, Lewis L, DeRamo C, Delgado O, Dugan-Rocha S, Miner G, Morgan M, Hawes A, Gill R, Celera, Holt RA, Adams MD, Amanatides PG, Baden-Tillson H, Barnstead M, Chin S, Evans CA, Ferriera S, Fosler C, Glodek A, Gu Z, Jennings D, Kraft CL, Nguyen T, Pfannkoch CM, Sitter C, Sutton GG, Venter JC, Woodage T, Smith D, Lee HM, Gustafson E, Cahill P, Kana A, Doucette-Stamm L, Weinstock K, Fechtel K, Weiss RB, Dunn DM, Green ED, Blakesley RW, Bouffard GG, De Jong PJ, Osoegawa K, Zhu B, Marra M, Schein J, Bosdet I, Fjell C, Jones S, Krzywinski M, Mathewson C, Siddiqui A, Wye N, McPherson J, Zhao S, Fraser CM, Shetty J, Shatsman S, Geer K, Chen Y, Abramzon S, Nierman WC, Havlak PH, Chen R, Durbin KJ, Egan A, Ren Y, Song XZ, Li B, Liu Y, Qin X, Cawley S, Worley KC, Cooney AJ, D'Souza LM, Martin K, Wu JQ, Gonzalez-Garay ML, Jackson AR, Kalafus KJ, McLeod MP, Milosavljevic A, Virk D, Volkov A, Wheeler DA, Zhang Z, Bailey JA, Eichler EE, Tuzun E, Birney E, Mongin E, Ureta-Vidal A, Woodwark C, Zdobnov E, Bork P, Suyama M, Torrents D, Alexandersson M, Trask BJ, Young JM, Huang H, Wang H, Xing H, Daniels S, Gietzen D, Schmidt J, Stevens K, Vitt U, Wingrove J, Camara F, Mar Alba M, Abril JF, Guigo R, Smit A, Dubchak I, Rubin EM, Couronne O, Poliakov A, Hubner N, Ganten D, Goesele C, Hummel O, Kreitler T, Lee YA, Monti J, Schulz H, Zimdahl H, Himmelbauer H, Lehrach H, Jacob HJ, Bromberg S, Gullings-Handley J, Jensen-Seaman MI, Kwitek AE, Lazar J, Pasko D, Tonellato PJ, Twigger S, Ponting CP, Duarte JM, Rice S, Goodstadt L, Beatson SA, Emes RD, Winter EE, Webber C, Brandt P, Nyakatura G, Adetobi M, Chiaromonte F, Elnitski L, Eswara P, Hardison RC, Hou M, Kolbe D, Makova K, Miller W, Nekrutenko A, Riemer C, Schwartz S, Taylor J, Yang S, Zhang Y, Lindpaintner K, Andrews TD, Caccamo M, Clamp M, Clarke L, Curwen V, Durbin R, Eyras E, Searle SM, Cooper GM, Batzoglou S, Brudno M, Sidow A, Stone EA, Venter JC, Payseur BA, Bourque G, Lopez-Otin C, Puente XS, Chakrabarti K, Chatterji S, Dewey C, Pachter L, Bray N, Yap VB, Caspi A, Tesler G, Pevzner PA, Haussler D, Roskin KM, Baertsch R, Clawson H, Furey TS, Hinrichs AS, Karolchik D, Kent WJ, Rosenbloom KR, Trumbower H, Weirauch M, Cooper DN, Stenson PD, Ma B, Brent M, Arumugam M, Shteynberg D, Copley RR, Taylor MS, Riethman H, Mudunuri U, Peterson J, Guyer M, Felsenfeld A, Old S, Mockrin S, Collins F: Genome sequence of the Brown Norway rat yields insights into mammalian evolution. Nature. 2004 Apr 1;428(6982):493-521. doi: 10.1038/nature02426.
Pubmed: 15057822
Jones DT, Reed RR: Molecular cloning of five GTP-binding protein cDNA species from rat olfactory neuroepithelium. J Biol Chem. 1987 Oct 15;262(29):14241-9.
Pubmed: 2820999
De Vries L, Fischer T, Tronchere H, Brothers GM, Strockbine B, Siderovski DP, Farquhar MG: Activator of G protein signaling 3 is a guanine dissociation inhibitor for Galpha i subunits. Proc Natl Acad Sci U S A. 2000 Dec 19;97(26):14364-9. doi: 10.1073/pnas.97.26.14364.
Pubmed: 11121039
Kimple RJ, De Vries L, Tronchere H, Behe CI, Morris RA, Gist Farquhar M, Siderovski DP: RGS12 and RGS14 GoLoco motifs are G alpha(i) interaction sites with guanine nucleotide dissociation inhibitor Activity. J Biol Chem. 2001 Aug 3;276(31):29275-81. doi: 10.1074/jbc.M103208200. Epub 2001 May 31.
Pubmed: 11387333
Wang XB, Funada M, Imai Y, Revay RS, Ujike H, Vandenbergh DJ, Uhl GR: rGbeta1: a psychostimulant-regulated gene essential for establishing cocaine sensitization. J Neurosci. 1997 Aug 1;17(15):5993-6000.
Pubmed: 9221795
Lundby A, Secher A, Lage K, Nordsborg NB, Dmytriyev A, Lundby C, Olsen JV: Quantitative maps of protein phosphorylation sites across 14 different rat organs and tissues. Nat Commun. 2012 Jun 6;3:876. doi: 10.1038/ncomms1871.
Pubmed: 22673903
Ruta M, Wolford R, Dhar R, Defeo-Jones D, Ellis RW, Scolnick EM: Nucleotide sequence of the two rat cellular rasH genes. Mol Cell Biol. 1986 May;6(5):1706-10. doi: 10.1128/mcb.6.5.1706.
Pubmed: 3023901
Damante G, Filetti S, Rapoport B: Nucleotide sequence and characterization of the 5' flanking region of the rat Ha-ras protooncogene. Proc Natl Acad Sci U S A. 1987 Feb;84(3):774-8. doi: 10.1073/pnas.84.3.774.
Pubmed: 3027702
Ishikawa F, Takaku F, Nagao M, Sugimura T: Rat c-raf oncogene activation by a rearrangement that produces a fused protein. Mol Cell Biol. 1987 Mar;7(3):1226-32. doi: 10.1128/mcb.7.3.1226.
Pubmed: 3550433
Pfleiderer P, Sumandea MP, Rybin VO, Wang C, Steinberg SF: Raf-1: a novel cardiac troponin T kinase. J Muscle Res Cell Motil. 2009;30(1-2):67-72. doi: 10.1007/s10974-009-9176-y. Epub 2009 Apr 21.
Pubmed: 19381846
Wu J, Harrison JK, Vincent LA, Haystead C, Haystead TA, Michel H, Hunt DF, Lynch KR, Sturgill TW: Molecular structure of a protein-tyrosine/threonine kinase activating p42 mitogen-activated protein (MAP) kinase: MAP kinase kinase. Proc Natl Acad Sci U S A. 1993 Jan 1;90(1):173-7. doi: 10.1073/pnas.90.1.173.
Pubmed: 8380494
Otsu M, Terada Y, Okayama H: Isolation of two members of the rat MAP kinase kinase gene family. FEBS Lett. 1993 Apr 12;320(3):246-50. doi: 10.1016/0014-5793(93)80596-m.
Pubmed: 8462694
Doring F, Drewes G, Berling B, Mandelkow EM: Cloning and sequencing of a cDNA encoding rat brain mitogen-activated protein (MAP) kinase activator. Gene. 1993 Sep 15;131(2):303-4. doi: 10.1016/0378-1119(93)90312-q.
Pubmed: 8406028
Marquardt B, Stabel S: Sequence of a rat cDNA encoding the ERK1-MAP kinase. Gene. 1992 Oct 21;120(2):297-9. doi: 10.1016/0378-1119(92)90109-3.
Pubmed: 1327976
Yung Y, Yao Z, Hanoch T, Seger R: ERK1b, a 46-kDa ERK isoform that is differentially regulated by MEK. J Biol Chem. 2000 May 26;275(21):15799-808. doi: 10.1074/jbc.M910060199.
Pubmed: 10748187
Boulton TG, Yancopoulos GD, Gregory JS, Slaughter C, Moomaw C, Hsu J, Cobb MH: An insulin-stimulated protein kinase similar to yeast kinases involved in cell cycle control. Science. 1990 Jul 6;249(4964):64-7. doi: 10.1126/science.2164259.
Pubmed: 2164259
Boulton TG, Nye SH, Robbins DJ, Ip NY, Radziejewska E, Morgenbesser SD, DePinho RA, Panayotatos N, Cobb MH, Yancopoulos GD: ERKs: a family of protein-serine/threonine kinases that are activated and tyrosine phosphorylated in response to insulin and NGF. Cell. 1991 May 17;65(4):663-75. doi: 10.1016/0092-8674(91)90098-j.
Pubmed: 2032290
Seger R, Ahn NG, Boulton TG, Yancopoulos GD, Panayotatos N, Radziejewska E, Ericsson L, Bratlien RL, Cobb MH, Krebs EG: Microtubule-associated protein 2 kinases, ERK1 and ERK2, undergo autophosphorylation on both tyrosine and threonine residues: implications for their mechanism of activation. Proc Natl Acad Sci U S A. 1991 Jul 15;88(14):6142-6. doi: 10.1073/pnas.88.14.6142.
Pubmed: 1712480
Lin TA, Kong X, Haystead TA, Pause A, Belsham G, Sonenberg N, Lawrence JC Jr: PHAS-I as a link between mitogen-activated protein kinase and translation initiation. Science. 1994 Oct 28;266(5185):653-6. doi: 10.1126/science.7939721.
Pubmed: 7939721
This pathway was propagated using PathWhiz -
Pon, A. et al. Pathways with PathWhiz (2015) Nucleic Acids Res. 43(Web Server issue): W552–W559.
Propagated from SMP0064625
