Pathway Description
Vinorelbine Action Pathway (New)
Homo sapiens
Category:
Metabolite Pathway
Sub-Category:
Drug Action
Created: 2020-08-04
Last Updated: 2023-10-25
Vinorelbine is a semi-synthetic third generation vinca alkaloid used in chemotherapy treatment for cervical, lung, breast, and esophageal cancers. It is differentiated from natural alkaloids by its eight-catharanine ring. Administered intravenously, vinorelbine acts on tumorous cells in the body to suppress their growth. Its main mechanism of action works by binding microtubules that are formed during the M phase of mitosis. This ceases the polymerization of microtubules, effectively pausing the cell at its G2/M phase. The disarray of microtubules induces two proteins; cellular tumor antigen p53 and cyclin-dependent kinase inhibitor p21. The latter protein works to inhibit cyclin-dependent kinases in the cell, which disrupt the phosphorylation of the apoptosis inhibitor Bcl-2. Bcl-2 suppresses apoptosis by regulating the permeability of the mitochondrial membrane but is unable to do so due to interrupted phosphorylation. The former protein, p53, acts on BAK and BAX to enact conformational changes, creating pores in the mitochondrial membrane that allow the exit of cytochrome c. Cytochrome c further activates caspases in the cell, which cleave essential cellular proteins. In this way, p53 and p21 work alongside each other to promote apoptosis and terminate unhealthy cells. Vinorelbine is especially valuable as a drug because it binds specifically to mitotic microtubules, likely decreasing its neurotoxicity.
References
Vinorelbine Pathway (New) References
Moudi M, Go R, Yien CY, Nazre M: Vinca alkaloids. Int J Prev Med. 2013 Nov;4(11):1231-5.
Pubmed: 24404355
Gregory, R., Smith, I. Vinorelbine – a clinical review. Br J Cancer 82, 1907–1913 (2000). https://doi.org/10.1054/bjoc.2000.1203
Ruvolo PP, Deng X, May WS: Phosphorylation of Bcl2 and regulation of apoptosis. Leukemia. 2001 Apr;15(4):515-22. doi: 10.1038/sj.leu.2402090.
Pubmed: 11368354
Brunelle JK, Letai A: Control of mitochondrial apoptosis by the Bcl-2 family. J Cell Sci. 2009 Feb 15;122(Pt 4):437-41. doi: 10.1242/jcs.031682.
Pubmed: 19193868
Breuss M, Heng JI, Poirier K, Tian G, Jaglin XH, Qu Z, Braun A, Gstrein T, Ngo L, Haas M, Bahi-Buisson N, Moutard ML, Passemard S, Verloes A, Gressens P, Xie Y, Robson KJ, Rani DS, Thangaraj K, Clausen T, Chelly J, Cowan NJ, Keays DA: Mutations in the beta-tubulin gene TUBB5 cause microcephaly with structural brain abnormalities. Cell Rep. 2012 Dec 27;2(6):1554-62. doi: 10.1016/j.celrep.2012.11.017. Epub 2012 Dec 13.
Pubmed: 23246003
Isrie M, Breuss M, Tian G, Hansen AH, Cristofoli F, Morandell J, Kupchinsky ZA, Sifrim A, Rodriguez-Rodriguez CM, Dapena EP, Doonanco K, Leonard N, Tinsa F, Moortgat S, Ulucan H, Koparir E, Karaca E, Katsanis N, Marton V, Vermeesch JR, Davis EE, Cowan NJ, Keays DA, Van Esch H: Mutations in Either TUBB or MAPRE2 Cause Circumferential Skin Creases Kunze Type. Am J Hum Genet. 2015 Dec 3;97(6):790-800. doi: 10.1016/j.ajhg.2015.10.014.
Pubmed: 26637975
Lee MG, Lewis SA, Wilde CD, Cowan NJ: Evolutionary history of a multigene family: an expressed human beta-tubulin gene and three processed pseudogenes. Cell. 1983 Jun;33(2):477-87. doi: 10.1016/0092-8674(83)90429-4.
Pubmed: 6688039
Zakut-Houri R, Bienz-Tadmor B, Givol D, Oren M: Human p53 cellular tumor antigen: cDNA sequence and expression in COS cells. EMBO J. 1985 May;4(5):1251-5.
Pubmed: 4006916
Lamb P, Crawford L: Characterization of the human p53 gene. Mol Cell Biol. 1986 May;6(5):1379-85. doi: 10.1128/mcb.6.5.1379.
Pubmed: 2946935
Harlow E, Williamson NM, Ralston R, Helfman DM, Adams TE: Molecular cloning and in vitro expression of a cDNA clone for human cellular tumor antigen p53. Mol Cell Biol. 1985 Jul;5(7):1601-10. doi: 10.1128/mcb.5.7.1601.
Pubmed: 3894933
Harper JW, Adami GR, Wei N, Keyomarsi K, Elledge SJ: The p21 Cdk-interacting protein Cip1 is a potent inhibitor of G1 cyclin-dependent kinases. Cell. 1993 Nov 19;75(4):805-16. doi: 10.1016/0092-8674(93)90499-g.
Pubmed: 8242751
el-Deiry WS, Tokino T, Velculescu VE, Levy DB, Parsons R, Trent JM, Lin D, Mercer WE, Kinzler KW, Vogelstein B: WAF1, a potential mediator of p53 tumor suppression. Cell. 1993 Nov 19;75(4):817-25. doi: 10.1016/0092-8674(93)90500-p.
Pubmed: 8242752
Xiong Y, Hannon GJ, Zhang H, Casso D, Kobayashi R, Beach D: p21 is a universal inhibitor of cyclin kinases. Nature. 1993 Dec 16;366(6456):701-4. doi: 10.1038/366701a0.
Pubmed: 8259214
Wolfel T, Hauer M, Schneider J, Serrano M, Wolfel C, Klehmann-Hieb E, De Plaen E, Hankeln T, Meyer zum Buschenfelde KH, Beach D: A p16INK4a-insensitive CDK4 mutant targeted by cytolytic T lymphocytes in a human melanoma. Science. 1995 Sep 1;269(5228):1281-4. doi: 10.1126/science.7652577.
Pubmed: 7652577
Zuo L, Weger J, Yang Q, Goldstein AM, Tucker MA, Walker GJ, Hayward N, Dracopoli NC: Germline mutations in the p16INK4a binding domain of CDK4 in familial melanoma. Nat Genet. 1996 Jan;12(1):97-9. doi: 10.1038/ng0196-97.
Pubmed: 8528263
Khatib ZA, Matsushime H, Valentine M, Shapiro DN, Sherr CJ, Look AT: Coamplification of the CDK4 gene with MDM2 and GLI in human sarcomas. Cancer Res. 1993 Nov 15;53(22):5535-41.
Pubmed: 8221695
Tanaka S, Louie DC, Kant JA, Reed JC: Frequent incidence of somatic mutations in translocated BCL2 oncogenes of non-Hodgkin's lymphomas. Blood. 1992 Jan 1;79(1):229-37.
Pubmed: 1339299
Tsujimoto Y, Croce CM: Analysis of the structure, transcripts, and protein products of bcl-2, the gene involved in human follicular lymphoma. Proc Natl Acad Sci U S A. 1986 Jul;83(14):5214-8. doi: 10.1073/pnas.83.14.5214.
Pubmed: 3523487
Eguchi Y, Ewert DL, Tsujimoto Y: Isolation and characterization of the chicken bcl-2 gene: expression in a variety of tissues including lymphoid and neuronal organs in adult and embryo. Nucleic Acids Res. 1992 Aug 25;20(16):4187-92. doi: 10.1093/nar/20.16.4187.
Pubmed: 1508712
Apte SS, Mattei MG, Olsen BR: Mapping of the human BAX gene to chromosome 19q13.3-q13.4 and isolation of a novel alternatively spliced transcript, BAX delta. Genomics. 1995 Apr 10;26(3):592-4.
Pubmed: 7607685
Oltvai ZN, Milliman CL, Korsmeyer SJ: Bcl-2 heterodimerizes in vivo with a conserved homolog, Bax, that accelerates programmed cell death. Cell. 1993 Aug 27;74(4):609-19. doi: 10.1016/0092-8674(93)90509-o.
Pubmed: 8358790
Shi B, Triebe D, Kajiji S, Iwata KK, Bruskin A, Mahajna J: Identification and characterization of baxepsilon, a novel bax variant missing the BH2 and the transmembrane domains. Biochem Biophys Res Commun. 1999 Jan 27;254(3):779-85. doi: 10.1006/bbrc.1998.0130.
Pubmed: 9920818
Farrow SN, White JH, Martinou I, Raven T, Pun KT, Grinham CJ, Martinou JC, Brown R: Cloning of a bcl-2 homologue by interaction with adenovirus E1B 19K. Nature. 1995 Apr 20;374(6524):731-3. doi: 10.1038/374731a0.
Pubmed: 7715729
Chittenden T, Harrington EA, O'Connor R, Flemington C, Lutz RJ, Evan GI, Guild BC: Induction of apoptosis by the Bcl-2 homologue Bak. Nature. 1995 Apr 20;374(6524):733-6. doi: 10.1038/374733a0.
Pubmed: 7715730
Kiefer MC, Brauer MJ, Powers VC, Wu JJ, Umansky SR, Tomei LD, Barr PJ: Modulation of apoptosis by the widely distributed Bcl-2 homologue Bak. Nature. 1995 Apr 20;374(6524):736-9. doi: 10.1038/374736a0.
Pubmed: 7715731
Evans MJ, Scarpulla RC: The human somatic cytochrome c gene: two classes of processed pseudogenes demarcate a period of rapid molecular evolution. Proc Natl Acad Sci U S A. 1988 Dec;85(24):9625-9. doi: 10.1073/pnas.85.24.9625.
Pubmed: 2849112
Ota T, Suzuki Y, Nishikawa T, Otsuki T, Sugiyama T, Irie R, Wakamatsu A, Hayashi K, Sato H, Nagai K, Kimura K, Makita H, Sekine M, Obayashi M, Nishi T, Shibahara T, Tanaka T, Ishii S, Yamamoto J, Saito K, Kawai Y, Isono Y, Nakamura Y, Nagahari K, Murakami K, Yasuda T, Iwayanagi T, Wagatsuma M, Shiratori A, Sudo H, Hosoiri T, Kaku Y, Kodaira H, Kondo H, Sugawara M, Takahashi M, Kanda K, Yokoi T, Furuya T, Kikkawa E, Omura Y, Abe K, Kamihara K, Katsuta N, Sato K, Tanikawa M, Yamazaki M, Ninomiya K, Ishibashi T, Yamashita H, Murakawa K, Fujimori K, Tanai H, Kimata M, Watanabe M, Hiraoka S, Chiba Y, Ishida S, Ono Y, Takiguchi S, Watanabe S, Yosida M, Hotuta T, Kusano J, Kanehori K, Takahashi-Fujii A, Hara H, Tanase TO, Nomura Y, Togiya S, Komai F, Hara R, Takeuchi K, Arita M, Imose N, Musashino K, Yuuki H, Oshima A, Sasaki N, Aotsuka S, Yoshikawa Y, Matsunawa H, Ichihara T, Shiohata N, Sano S, Moriya S, Momiyama H, Satoh N, Takami S, Terashima Y, Suzuki O, Nakagawa S, Senoh A, Mizoguchi H, Goto Y, Shimizu F, Wakebe H, Hishigaki H, Watanabe T, Sugiyama A, Takemoto M, Kawakami B, Yamazaki M, Watanabe K, Kumagai A, Itakura S, Fukuzumi Y, Fujimori Y, Komiyama M, Tashiro H, Tanigami A, Fujiwara T, Ono T, Yamada K, Fujii Y, Ozaki K, Hirao M, Ohmori Y, Kawabata A, Hikiji T, Kobatake N, Inagaki H, Ikema Y, Okamoto S, Okitani R, Kawakami T, Noguchi S, Itoh T, Shigeta K, Senba T, Matsumura K, Nakajima Y, Mizuno T, Morinaga M, Sasaki M, Togashi T, Oyama M, Hata H, Watanabe M, Komatsu T, Mizushima-Sugano J, Satoh T, Shirai Y, Takahashi Y, Nakagawa K, Okumura K, Nagase T, Nomura N, Kikuchi H, Masuho Y, Yamashita R, Nakai K, Yada T, Nakamura Y, Ohara O, Isogai T, Sugano S: Complete sequencing and characterization of 21,243 full-length human cDNAs. Nat Genet. 2004 Jan;36(1):40-5. doi: 10.1038/ng1285. Epub 2003 Dec 21.
Pubmed: 14702039
Bechtel S, Rosenfelder H, Duda A, Schmidt CP, Ernst U, Wellenreuther R, Mehrle A, Schuster C, Bahr A, Blocker H, Heubner D, Hoerlein A, Michel G, Wedler H, Kohrer K, Ottenwalder B, Poustka A, Wiemann S, Schupp I: The full-ORF clone resource of the German cDNA Consortium. BMC Genomics. 2007 Oct 31;8:399. doi: 10.1186/1471-2164-8-399.
Pubmed: 17974005
