Pathway Description
Circadian Rhythms
Homo sapiens
Category:
Protein Pathway
Sub-Categories:
Gene Regulatory
Kinase Signaling
Created: 2018-08-15
Last Updated: 2019-08-16
The nuclear entry of clock gene products is required to establish the negative feed back loop- a key step in proper circadian rhythm. Heterodimerization of clock proteins PER and CRY is required for translocation to the nucleus. Nuclear entry of PER can be regulated by mammalian casein kinase I (CK1). Once in the nucleus, PER and CRY proteins appear to differentially inhibit the transactivation by CLOCK/BMAL1. Proteins like REV-ERBa and DEC also regulate the transcriptional activation by CLOCK/BMAL1. In addition, CRY, PER, and BMAL1-CLOCK play bidirectional roles in transcription resulting in interactivating feedback loops. The expression of BMAL1 and CLOCK can be upregulated by CRY and PER. Such loops are believed to be important in the stability and persistence of circadian rhythm.
References
Circadian Rhythms References
Akagi R, Akatsu Y, Fisch KM, Alvarez-Garcia O, Teramura T, Muramatsu Y, Saito M, Sasho T, Su AI, Lotz MK: Dysregulated circadian rhythm pathway in human osteoarthritis: NR1D1 and BMAL1 suppression alters TGF-beta signaling in chondrocytes. Osteoarthritis Cartilage. 2017 Jun;25(6):943-951. doi: 10.1016/j.joca.2016.11.007. Epub 2016 Nov 22.
Pubmed: 27884645
Winter SL, Bosnoyan-Collins L, Pinnaduwage D, Andrulis IL: Expression of the circadian clock genes Per1 and Per2 in sporadic and familial breast tumors. Neoplasia. 2007 Oct;9(10):797-800.
Pubmed: 17971899
Rong-ChiHuang. (2018) The discoveries of molecular mechanisms for the circadian rhythm: The 2017 Nobel Prize in Physiology or Medicine. Biomedical Journal, Volume 41, Issue 1, February 2018, Pages 5-8
Miyazaki K, Nagase T, Mesaki M, Narukawa J, Ohara O, Ishida N: Phosphorylation of clock protein PER1 regulates its circadian degradation in normal human fibroblasts. Biochem J. 2004 May 15;380(Pt 1):95-103. doi: 10.1042/BJ20031308.
Pubmed: 14750904
Sun ZS, Albrecht U, Zhuchenko O, Bailey J, Eichele G, Lee CC: RIGUI, a putative mammalian ortholog of the Drosophila period gene. Cell. 1997 Sep 19;90(6):1003-11. doi: 10.1016/s0092-8674(00)80366-9.
Pubmed: 9323128
Tei H, Okamura H, Shigeyoshi Y, Fukuhara C, Ozawa R, Hirose M, Sakaki Y: Circadian oscillation of a mammalian homologue of the Drosophila period gene. Nature. 1997 Oct 2;389(6650):512-6. doi: 10.1038/39086.
Pubmed: 9333243
Griffin EA Jr, Staknis D, Weitz CJ: Light-independent role of CRY1 and CRY2 in the mammalian circadian clock. Science. 1999 Oct 22;286(5440):768-71. doi: 10.1126/science.286.5440.768.
Pubmed: 10531061
Patke A, Murphy PJ, Onat OE, Krieger AC, Ozcelik T, Campbell SS, Young MW: Mutation of the Human Circadian Clock Gene CRY1 in Familial Delayed Sleep Phase Disorder. Cell. 2017 Apr 6;169(2):203-215.e13. doi: 10.1016/j.cell.2017.03.027.
Pubmed: 28388406
Hsu DS, Zhao X, Zhao S, Kazantsev A, Wang RP, Todo T, Wei YF, Sancar A: Putative human blue-light photoreceptors hCRY1 and hCRY2 are flavoproteins. Biochemistry. 1996 Nov 5;35(44):13871-7. doi: 10.1021/bi962209o.
Pubmed: 8909283
Fish KJ, Cegielska A, Getman ME, Landes GM, Virshup DM: Isolation and characterization of human casein kinase I epsilon (CKI), a novel member of the CKI gene family. J Biol Chem. 1995 Jun 23;270(25):14875-83. doi: 10.1074/jbc.270.25.14875.
Pubmed: 7797465
Okamura A, Iwata N, Nagata A, Tamekane A, Shimoyama M, Gomyo H, Yakushijin K, Urahama N, Hamaguchi M, Fukui C, Chihara K, Ito M, Matsui T: Involvement of casein kinase Iepsilon in cytokine-induced granulocytic differentiation. Blood. 2004 Apr 15;103(8):2997-3004. doi: 10.1182/blood-2003-08-2768. Epub 2004 Jan 8.
Pubmed: 15070676
Collins JE, Wright CL, Edwards CA, Davis MP, Grinham JA, Cole CG, Goward ME, Aguado B, Mallya M, Mokrab Y, Huckle EJ, Beare DM, Dunham I: A genome annotation-driven approach to cloning the human ORFeome. Genome Biol. 2004;5(10):R84. doi: 10.1186/gb-2004-5-10-r84. Epub 2004 Sep 30.
Pubmed: 15461802
Lowe DG, Chang MS, Hellmiss R, Chen E, Singh S, Garbers DL, Goeddel DV: Human atrial natriuretic peptide receptor defines a new paradigm for second messenger signal transduction. EMBO J. 1989 May;8(5):1377-84.
Pubmed: 2569967
Takahashi Y, Nakayama T, Soma M, Izumi Y, Kanmatsuse K: Organization of the human natriuretic peptide receptor A gene. Biochem Biophys Res Commun. 1998 May 29;246(3):736-9. doi: 10.1006/bbrc.1998.8693.
Pubmed: 9618281
Gregory SG, Barlow KF, McLay KE, Kaul R, Swarbreck D, Dunham A, Scott CE, Howe KL, Woodfine K, Spencer CC, Jones MC, Gillson C, Searle S, Zhou Y, Kokocinski F, McDonald L, Evans R, Phillips K, Atkinson A, Cooper R, Jones C, Hall RE, Andrews TD, Lloyd C, Ainscough R, Almeida JP, Ambrose KD, Anderson F, Andrew RW, Ashwell RI, Aubin K, Babbage AK, Bagguley CL, Bailey J, Beasley H, Bethel G, Bird CP, Bray-Allen S, Brown JY, Brown AJ, Buckley D, Burton J, Bye J, Carder C, Chapman JC, Clark SY, Clarke G, Clee C, Cobley V, Collier RE, Corby N, Coville GJ, Davies J, Deadman R, Dunn M, Earthrowl M, Ellington AG, Errington H, Frankish A, Frankland J, French L, Garner P, Garnett J, Gay L, Ghori MR, Gibson R, Gilby LM, Gillett W, Glithero RJ, Grafham DV, Griffiths C, Griffiths-Jones S, Grocock R, Hammond S, Harrison ES, Hart E, Haugen E, Heath PD, Holmes S, Holt K, Howden PJ, Hunt AR, Hunt SE, Hunter G, Isherwood J, James R, Johnson C, Johnson D, Joy A, Kay M, Kershaw JK, Kibukawa M, Kimberley AM, King A, Knights AJ, Lad H, Laird G, Lawlor S, Leongamornlert DA, Lloyd DM, Loveland J, Lovell J, Lush MJ, Lyne R, Martin S, Mashreghi-Mohammadi M, Matthews L, Matthews NS, McLaren S, Milne S, Mistry S, Moore MJ, Nickerson T, O'Dell CN, Oliver K, Palmeiri A, Palmer SA, Parker A, Patel D, Pearce AV, Peck AI, Pelan S, Phelps K, Phillimore BJ, Plumb R, Rajan J, Raymond C, Rouse G, Saenphimmachak C, Sehra HK, Sheridan E, Shownkeen R, Sims S, Skuce CD, Smith M, Steward C, Subramanian S, Sycamore N, Tracey A, Tromans A, Van Helmond Z, Wall M, Wallis JM, White S, Whitehead SL, Wilkinson JE, Willey DL, Williams H, Wilming L, Wray PW, Wu Z, Coulson A, Vaudin M, Sulston JE, Durbin R, Hubbard T, Wooster R, Dunham I, Carter NP, McVean G, Ross MT, Harrow J, Olson MV, Beck S, Rogers J, Bentley DR, Banerjee R, Bryant SP, Burford DC, Burrill WD, Clegg SM, Dhami P, Dovey O, Faulkner LM, Gribble SM, Langford CF, Pandian RD, Porter KM, Prigmore E: The DNA sequence and biological annotation of human chromosome 1. Nature. 2006 May 18;441(7091):315-21. doi: 10.1038/nature04727.
Pubmed: 16710414
Steeves TD, King DP, Zhao Y, Sangoram AM, Du F, Bowcock AM, Moore RY, Takahashi JS: Molecular cloning and characterization of the human CLOCK gene: expression in the suprachiasmatic nuclei. Genomics. 1999 Apr 15;57(2):189-200. doi: 10.1006/geno.1998.5675.
Pubmed: 10198158
Li R, Yue J, Zhang Y, Zhou L, Hao W, Yuan J, Qiang B, Ding JM, Peng X, Cao JM: CLOCK/BMAL1 regulates human nocturnin transcription through binding to the E-box of nocturnin promoter. Mol Cell Biochem. 2008 Oct;317(1-2):169-77. doi: 10.1007/s11010-008-9846-x. Epub 2008 Jun 28.
Pubmed: 18587630
Ward SM, Fernando SJ, Hou TY, Duffield GE: The transcriptional repressor ID2 can interact with the canonical clock components CLOCK and BMAL1 and mediate inhibitory effects on mPer1 expression. J Biol Chem. 2010 Dec 10;285(50):38987-9000. doi: 10.1074/jbc.M110.175182. Epub 2010 Sep 22.
Pubmed: 20861012
