Pathway Description
Complement Pathway
Mus musculus
Category:
Protein Pathway
Sub-Categories:
Immunological
Kinase Signaling
Pathogen-Activated Signaling
Cellular Response
Created: 2018-09-20
Last Updated: 2019-08-16
The complement system includes three separate pathways that lead to complement's activation. These pathways all have different molecules that trigger their activation, but all of them lead to a response by phagocytes as part of a response by the innate immune system.
In the alternative pathway, complement factor C3 can spontaneously hydrolyze to form a complex with water. Complement factor D is a protease that can work at the same time, and it cleaves complement factor B into factors Ba and Bb. the C3(H2O) complex can bind to factor Bb, which is a C3 convertase, and works to cleave factor C3 into C3a and C3b more quickly. The C3(H2O)Bb complex also binds factor B, leading to easier cleavage into Ba and Bb by factor D. Following this, complement factor C3b can bind to the surface of cells, and on host cells, proteins on the cell membrane can bind to C3b, preventing it from forming complement factor C5 convertase. However, on pathogen cells, these proteins do not exist, complement factor Bb can bind to two molecules of C3b, forming a C5-convertase which is the end point of the other two pathways.
In the lectin pathway, mannan-binding lectin serine proteases (MASP) 1 and 2, as well as mannose-binding protein C bind to carbohydrates, specifically mannose, glucose and sugars with specific hydroxide group placements. These sugars are found in the cell walls of bacteria such as salmonella and listeria, as well as some viruses, including HIV-1, and fungal pathogens, such as candida. After the sugar is bound by the proteins, it activates the serine proteases, which then can cleave complement C2 and C4 into C2a, C2b, C4a and C4b respectively. Factors C4b and C2a (sometimes called C2b) can interact to form C3 convertase, which is identical in function to the C3 convertase formed by the alternative pathway, and it works to cleave C3 into C3a and C3b more quickly. Finally for this pathway, a molecule of C3b interacts with the preexisting C3 convertase complex, forming the C5 convertase complex that cleaves factor C5 into C5a and C5b.
The final pathway that leads to this point is the classical complement pathway. This pathway is activated by the binding of aggregated antibody-antigen complexes, as well as components of viral and bacterial cells such as lipopolysaccharides, to the C1q protein. C1q is part of the C1 complex, which also includes C1s and C1r. Binding of a substance to C1q causes a conformational change in C1r and C1s, allowing C1s to become an active protease, which then is able to cleave complement factors C2 and C4 into their a and b fragments, as in the lectin pathway. The remainder of the pathway is identical to that of the lectin pathway.
Finally, after cleavage of C5 into C5a and C5b by any of the pathways, complement componenets C6, 7, 8 and 9 can interact with component C5b in order to form the membrane attack complex. This complex attaches to the plasma membrane of pathogen cells, forming a hole in the membrane and allowing diffusion of molecules in the cell, and eventually cell death if enough attack complex form.
References
Complement Pathway References
Sottrup-Jensen L, Stepanik TM, Kristensen T, Lonblad PB, Jones CM, Wierzbicki DM, Magnusson S, Domdey H, Wetsel RA, Lundwall A, et al.: Common evolutionary origin of alpha 2-macroglobulin and complement components C3 and C4. Proc Natl Acad Sci U S A. 1985 Jan;82(1):9-13. doi: 10.1073/pnas.82.1.9.
Pubmed: 2578664
Fey G, Domdey H, Wiebauer K, Whitehead AS, Odink K: Structure and expression of the C3 gene. Springer Semin Immunopathol. 1983;6(2-3):119-47.
Pubmed: 6356427
Hamada J, Cavanaugh PG, Miki K, Nicolson GL: A paracrine migration-stimulating factor for metastatic tumor cells secreted by mouse hepatic sinusoidal endothelial cells: identification as complement component C3b. Cancer Res. 1993 Sep 15;53(18):4418-23.
Pubmed: 8364938
Nonaka M, Nakayama K, Yeul YD, Takahashi M: Complete nucleotide and derived amino acid sequences of the fourth component of mouse complement (C4). Evolutionary aspects. J Biol Chem. 1985 Sep 15;260(20):10936-43.
Pubmed: 2993295
Sepich DS, Noonan DJ, Ogata RT: Complete cDNA sequence of the fourth component of murine complement. Proc Natl Acad Sci U S A. 1985 Sep;82(17):5895-9. doi: 10.1073/pnas.82.17.5895.
Pubmed: 3862104
Ogata RT, Rosa PA, Zepf NE: Sequence of the gene for murine complement component C4. J Biol Chem. 1989 Oct 5;264(28):16565-72.
Pubmed: 2777798
Wetsel RA, Fleischer DT, Haviland DL: Deficiency of the murine fifth complement component (C5). A 2-base pair gene deletion in a 5'-exon. J Biol Chem. 1990 Feb 15;265(5):2435-40.
Pubmed: 2303408
Haviland DL, Haviland JC, Fleischer DT, Wetsel RA: Structure of the murine fifth complement component (C5) gene. A large, highly interrupted gene with a variant donor splice site and organizational homology with the third and fourth complement component genes. J Biol Chem. 1991 Jun 25;266(18):11818-25.
Pubmed: 1711041
Church DM, Goodstadt L, Hillier LW, Zody MC, Goldstein S, She X, Bult CJ, Agarwala R, Cherry JL, DiCuccio M, Hlavina W, Kapustin Y, Meric P, Maglott D, Birtle Z, Marques AC, Graves T, Zhou S, Teague B, Potamousis K, Churas C, Place M, Herschleb J, Runnheim R, Forrest D, Amos-Landgraf J, Schwartz DC, Cheng Z, Lindblad-Toh K, Eichler EE, Ponting CP: Lineage-specific biology revealed by a finished genome assembly of the mouse. PLoS Biol. 2009 May 5;7(5):e1000112. doi: 10.1371/journal.pbio.1000112. Epub 2009 May 26.
Pubmed: 19468303
This pathway was propagated using PathWhiz -
Pon, A. et al. Pathways with PathWhiz (2015) Nucleic Acids Res. 43(Web Server issue): W552–W559.
Propagated from SMP0063814
